Domino-KF212

Full range compact passive stainless steel speakers with two 6'' drivers

The largest and most powerful of the Domino line is the Domino-KF212. Comprised of a 12" coaxial transducer with a titanium dome and a 12" passive radiator, the Domino-KF212 really packs a punch.

At just 20 cm deep, the Domino-KF212 is the ideal solution for clubs and lounges. Wall brackets are included, while other useful tools are available for purchase, like the flush mount recessing frame, K-WF212, used for wall insets to further hide the speakers.

Features

Compatible with Any Amplifier

Color Customizable

Premium Finishes

Visually Discreet

Weather Resistant

Full-Range Frequency Response

Selectable Impedance

Specifications

Acoustics
Power Handling	700W
Impedance	8 Ohm
Frequency range	40Hz-19000Hz
SPL 1W/1mt	100 db
Maximum SPL3	124dB (cont) - 130dB (peak)
Coverage
Horizontal	90°
Vertical	90°
Crossover
Coaxial	Internal Passive Crossover
Frequency	2500 Hz
Transducers
Type	1 x 12” coaxial: ferrite magnet woofer with 3” voice coil + titanium dome with 1.7” voice coil
Type	1 x 12” passive radiator
Power Audio in/out
Connectors	1 x 4-pin Phoenix connector (only 2 pins used)
Recommended Amplifier
Type	KA84
Certifications
IP	56 (More complete water protection with K-KUIP accessory)
Physical Overview
Dimensions	33.0 x 65.0 x 20.0 cm (12.99”x 25.59”x 7.87”) (1)
Weight	23.5 Kg (51.80 lb)
