Type

Passive 2-way enclosure

Powering and driving system

LA4X, LA8, LA12X

Bandwidth

59Hz - 20kHz ([X12] preset)

Maximum SPL

136dB ([X12] preset)

Nominal directivity

Axisymmetric100°

Transducers

LF: 1 × 12’’, bass reflex

HF: 1 × 3’’compression

Rigging

2 × handles

DIN580-compatible M8 threaded insert

4 × M10 threaded inserts

2 × 35 mm pole sockets

Dimension(W×H×D)

430 x 496 x 375mm

16.9 x 19.5 x 14.8in

Net weight

20kg / 44.1lbs.
