PRODUCTS

Bar

Frequency response special design to avoid auditory fatigue

Theatre

Rotatable and asymmetrical horn

Stage Monitor

13x M8 rigging points

Pole mount socket

Frequency Respond

              60 Hz ~ 18 kHz(±3 dB) ;  50 Hz ~ 20 kHz(-10 dB)

Nominal Coverage(- 6 dB)

              50°-100°（H）55°(V) Constant Direction

Sensitivity(@1w/1m)

              96 dB SPL

Powerating(AES)

              400 W

Nominal Impedance

              8 ohm

Maximum SPL

              122 dB (Continuous) 128 dB (Peak)

Drivers

              LF:1 x 12"（75 mm voice coil) woofer

              HF:1 x 44 mm  voice coil compression driver

Dimension

                 576x372x384 mm

Weight

                 23Kg

Speaker Cables

                1+1-（Signal Input & Loop）

Connectors

                2 x NL4MP Neutrik Speakon connectors

Materials

                18 mm，24 mm birch plywood

Finish

                Black water paintings

Grille

                Black epoxy mesh grille with acoustically

               reticulated foam
